Wiring

by **Bacon3.0r** » Wed Nov 26, 2014 11:42 am

I'm in the US so getting blitzen wiring is impossible here. I did a motor swap and had a 05 blitzen ecu imported in from Australia. So my question is does anyone have a wiring diagram for a 2005 liberty blitzen 3.0 with a manual transmission.

by **WIDELOAD** » Wed Nov 26, 2014 11:44 am

Blitzen ECU is the same as a normal 3.0R ECU to the best of my knowledge.

The Blizten was just a styling pack here in Aus.

by **Bacon3.0r** » Wed Nov 26, 2014 11:53 am

I guess the biggest issue I have is that in the US the 3.0r was not offered with a manual transmission so all the wiring diagrams I have found don't give pin outs for the clutch switch so I was hoping someone in aus has the aus version

by **HardwareBoB** » Wed Nov 26, 2014 12:14 pm

http://www.tangcla.com/temp/bl5/reference/AUDM%20Legacy/

by **Bacon3.0r** » Wed Nov 26, 2014 12:38 pm

Unfortunately that link doesn't work because it doesn't list for the manual transmission for the 3.0

by **WIDELOAD** » Wed Nov 26, 2014 4:44 pm

Some quick google-fu bought up this site.

Has the wiring diagrams listed for the RHD 3.0R. So hopefully has the pin-outs you need.

http://jdmfsm.info/Auto/Japan/Subaru/Le ... index.html

by **Bacon3.0r** » Wed Nov 26, 2014 11:26 pm

That looks like it will work. I'm going to try it today and I'll let you know. Thanks

by **gotasuby** » Thu Nov 27, 2014 9:56 am

This is pin out I made for 2005 3.0r manual. There a couple of pins missing as I didn't need them for my ecu swap.

by **Bacon3.0r** » Thu Nov 27, 2014 10:34 am

What motor did you have in there originally and were those the only changes you had to make

by **gotasuby** » Thu Nov 27, 2014 12:22 pm

I have a 3.0r factory and have moddify it to have aftermarket vipec ecu and now in the process of turboing it.

by **KiDo_Tuning** » Fri Nov 28, 2014 12:29 am

Which year model Legacy though? The Blitzen DOXJ001M ECU is the first of the 1Mb ECU's and had a few changes to the loom

by **Bacon3.0r** » Fri Nov 28, 2014 12:33 am

I'm told it was out of a 2005 blitzen. It has Q1 on the top cover. I don't know if that helps.

by **gotasuby** » Fri Nov 28, 2014 5:53 am

2005 adm 3.0r

by **KiDo_Tuning** » Fri Nov 28, 2014 7:58 pm

Bacon3.0r wrote:I'm told it was out of a 2005 blitzen. It has Q1 on the top cover. I don't know if that helps.

Got a photo of the inside of the ECU?

2003/04/05 were a 512Kb ECU
2006 onwards(which includes all Blitzen models) are a 1024Kb ECU and have some eletrical loom changes, albeit minor

Blitzen was still a standard H6 tune, nothing special tune wise

by **Bacon3.0r** » Fri Nov 28, 2014 9:39 pm

This page isn't letting me upload the photo. Can you tell me what I need to look for
